Powerhand EX Forestry Grapple

Product catalog summary
Overview: The Powerhand EX Series Grapple is a heavy-duty forestry biomass grapple designed for installation on excavators or large cranes. It is optimized for tasks such as feeding chippers, handling brash, log handling, and general forestry work.
Specifications:
  • Models: EX25, EX28, EX36, EX40
  • Capacity: Ranges from 0.25 m² to 0.40 m²
  • Weight: Ranges from 323 kg to 875 kg
  • Opening Dimensions: Varying maximum openings from 1641 mm to 2137 mm
  • Excavator Size Compatibility: Suitable for excavators ranging from 8,000 kg to 30,000 kg
Design Features:
  • Optimized for rigid excavator mounting via tilt rotator or rigid rotator assembly, with options for swing link mounting.
  • EX25 model features 5 solid 30mm Hardox tines, while other models feature 5 solid 50mm tines, enhancing performance in demanding applications.
Applications: Ideal for forestry tasks including site clearing, log handling, and biomass processing.
See more

Catalog excerpts

Powerhand EX Forestry Grapple-1

powerhand DATA SHEET The Powerhand eX forestry grapple is the ultimate heavy duty forestry biomass grapple for installation on an excavator or large crane. The Powerhand EX grapple design has been optimised for tasks such as feeding chippers, handling brash while clearing sites, log handling and general forestry work. Designed for use on excavators from 8 tonnes to 30 tonnes, the eX Series is ideal for rigid excavator mounting both direct via a tilt rotator or rigid rotator assembly. Also available for swing link mounting. The EX25 grapple legs feature 5 solid 30mm Hardox tines and other models feature 5 solid 50mm tines, allowing Powerhand EX biomass grapples to excel in this demanding application. Powerhand is a division of Wm Clark and Son (Parkgate] Ltd, Parkgate, Dumfries, DG1 3NB +44 (0)1387 860 241 - [email protected] - www.powerhand.com

 Open the catalog to page 1
