HDL
8Pages

ELECTRONIC CLIMATE CONTROL

Half DIN Dimension Line This fully equipped automatic line is able to meet most of the requirements in the climate control automotive field. The mechanical dimensions are half the size of the standard car radio (half DIN). COMES control units are developed to get the maximum flexibility. If you are interested in different functions or other modifications, please do not hesitate to contact our sales team who will provide you with professional assistance. GENERAL PERFORMANCE, ELECTRONICAL AND ENVIRONMENTAL TESTS Operating Voltage Range: 10.5÷16V / 18÷32V Nominal Power Supply Voltage: 12V /...

FUNCTIONAL OVERVIEW The control unit features eight push buttons and an LCD display, as below: • Two push buttons for temperature adjustment • Two push buttons for air flow • AUTO push button for full auto mode • Recirculation push button • LCD: customised icons, TN, Transflective Positive, 12:00 or 6:00 o'clock viewing direction When activating a function, the relevant icon becomes visible on the LCD display. The control unit is fully backlit (all functions of the control unit are backlit to allow the user to easily find them in the hours of darkness) and available for both 12V and 24V...

Cooling Version Relay Blower Speed Recirculation Push Button PART NUMBER Control Unit Anti-icing Sensor Kit External Temperature Sensor Internal Temperature Sensor Connector and Pin Kit Complete Kit (Relays not included) Cooling Version Electronic Blower Speed Regulator Recirculation Push Button PART NUMBER Control Unit Anti-icing Sensor Kit Electronic Blower Speed Regulator Kit External Temperature Sensor Internal Temperature Sensor Connector and Pin Kit Complete Kit (Relay not included) Climate Version Solenoid Water Valve Relay Blower Speed Recirculation Push Button PART NUMBER Control...

Climate Version Solenoid Water Valve Electronic Blower Speed Regulator Recirculation Push Button PART NUMBER Control Unit Solenoid Water Valve Kit Electronic Blower Speed Regulator Kit Anti-icing Sensor Kit External Temperature Sensor Internal Temperature Sensor Connector and Pin Kit Complete Kit (Relay not included) Climate Version DC Motor Water Valve Relay Blower Speed Recirculation Push Button Control Unit DC Motor Water Valve Kit Anti-icing Sensor Kit External Temperature Sensor Internal Temperature Sensor Connector and Pin Kit Complete Kit (Relays not included) Climate Version DC...

Electronic Blower Speed Regulator Solenoid Water Valve External Temperature Sensor DC Motor Water Valve Internal Temperature Sensor Anti-icing Sensor

COMES Electronic Climate Control Via Don Fracassi 25/27 20008 Bareggio – Milano – Italy
