Fruit & Nut Harvester OE 5.1 Shake & Catch Rocket Inter Action GmbH - Made in Germany

Continuous working fruit harvester for industrial fruit

Fruit Harvester OE4 History of developement:

Fruit Harvester OE4 History of developement: First machine in practical harvest in 1988

FRUMAC 5 AGRICULTURE TECHNOLOGY

Fruit Harvester OE4 History of developement: Change to self-propelled machines in 2002

Fruit Harvester OE4 Technical description: The harvester is based on the principle of a single-machine system. The shaking and catching function is united in one machine moving laterally next to the tree.

Fruit Harvester OE4 Technical description: This type of machine uses a continuous harvesting process. The trees are harvested in continuous drive without any intermediate stop. For this purpose, the machine is equipped with a continuous shaker, which recognizes and grab the trees by itself. A special electro-hydraulic mechanism controls the process.

Fruit Harvester OE4 Technical description: After the shaking process the fruits do not fall to the ground, a plan-covered catching screen is led over the row of trees. From the machine side and the catching screen, the fruits reach the central conveyor belt via a specially designed center seal. One central conveyor belt, one elevator and one cleaning stage transport the fruits to a container vehicle driving in the adjacent row.

Fruit Harvester OE4 Technical description: The harvester has a height and side-level regulated landing gear, so it is able to adapt to the most complicated terrain conditions.

Fruit Harvester OE4 Technical description: The operator can execute and watch all functions of the machine from the driver's station. All working and delivery processes of the machine are powered by electro-hydraulic systems.

Fruit Harvester OE 4.5 -> next chapter 2022 Version 2022 full automatic steering and computer controlled: Project and Product developed by FRUMACO

Fruit Harvester OE 4.5 actual version

Fruit Harvester OE 4.5 actual version

Fruit Harvester OE 4.5 actual version

Our Customer 8000 ha Apple Orchards

AGRICULTURE TECHNOLOGY

AGRICULTURE TECHNOLOGY

AGRICULTURE TECHNOLOGY

Fruit Harvester OE 4.5 street legal & road license

perfect view to the trees and the orchard

Full control, check & use the OE 4.5 from the cabin-seat. 4.0 Telematic and service online check is standard.

Fruit Harvester OE 4.5 Limitations: This machine can not be used in newly planted orchards if the trees are still too small. This machine can not be used to harvest fruit for the fresh market, only for industrial, dry crops and juice crops.

Technical specifications: Machine system Operation limit Operation Harvest method Removal of goods Single machine system Self-propelled fruit harvester 3 wheel landing gear 3 wheel drive 3 wheel steering Parallel driving separate vehicle to collect the crop Harvest 15% up and down hill (self levelling) 12% cross hill (with sidelevel only, self levelling) Transport 20% up and down hill 15% cross hill One-man operated Continuously working shaker in a "Shake and Catch" process Transfer the crop from the conveyor system of the harvester to a parallel driving container vehicle in the adjacent row...

Technical specifications: Harvesting capacity Conveyor capacity Cleaning of the goods Road transport Technical specifications: Harvesting capacity Conveyor capacity Cleaning of the goods Road transport Fruit Harvester OE 4.5 Up to 7-8 trees / min in the working process under perfect conditions Up to 25 t/h (apples) sour cherries (Almonds, Pistachios and other on request) Separation of the crop from leaf and wood parts as pre-cleaning Suitable for road transport - ist self propelled and street legal with road license 4m-version only (5 m - version with special law documents)

Row spacing from trunk to trunk Tree distance in the row from trunk to trunk Trunk diameter Free and clean trunk height Tree height Crown width Trunk quality (<5,0 m possible, not street legal) <3,5 m (larger version on request) all trees in a straight line ideal is equally FRUMAC 5 AGRICULTURE TECHNOLOGY

Orchard - Front view Orchard - Operation limit cross hill FRUMAC 5 AGRICULTURE TECHNOLOGY

Fruit Harvester OE4 No good conditions for the OE4 are: … trees grows on trellis … poles at each tree

Fruit Harvester OE4 No good conditions for the OE4 are: … dirty ground … tilted trees and serpentine lines

... irrigation system above the ground ... hail nets FRUMAC 5 AGRICULTURE TECHNOLOGY

Fruit Harvester OE4 No good conditions for the OE4 are: … trees witch big grafting knots

Danke & thank you & gracies Tom Neumann, CEO FRUMACO Rocket Inter Action GmbH - Made in Germany
