Horse Stalls
14Pages

Custom made designs Horse Stalls We are happy to assist you with the implementation of your individual wishes for your stables. You can rely on our experience and our expertise - the well-being of your horse is very important to us! TRUST IN US! 25 Uwe Kraft Reitsportgeräte & Metallbau GmbH Riedwasen 10 D-74586 Frankenhardt-Honhardt email: info@kraft-fuehranlagen.de Kraft ...keeps your horses fit! www.kraft-fuehranlagen.de Horse Stalls © KRAFT

Everything revolves around horses for us. Everything we do is focused on their well-being and care. Horses love exercising and need a place to rest. We bring both together. We have been experts in equestrian exercise worldwide for decades. Customers often asked us about horse stalls and associated stable equipment. With the addition of our top-quality range of horse stalls, we will offer "one stop shopping" where it is desired. The larger product range enables the implementation of larger overall projects. Exercise and rest are now combined. Look at our stalls in this catalog. From the...

KRAFT Horse Stalls KRAFT Horse Stalls Steel spindles: Ø 22 mm, gap: 60 mm Frame Profile: C-Profile A horse stall with an excellent price-performance ratio for everyday needs. Standard front walls with sliding doors, dividing walls and, if required, rear walls. It is easy to plan and design stable stalls quickly and easily. All doors can be opened from inside and outside. A hinged opening can be installed into the door as an option. Steel spindles: Ø 28 mm, gap: 53 mm Frame profile: double-walled C-profile The KRAFT cleaning system can be combined with the Standard stalls to ease the work...

Front, partition and rear walls Feeding panels DESIGN EXAMPLES TECHNICAL DETAILS FRONT WALLS PARTITION AND REAR WALLS HALF CLOSED - With sliding door - Sliding door with integrated window - Casters with ball bearings glide in a solid closed track - Spring loaded lock - Sturdy construction: welded sealed frames - All steel parts are hot-dip galvanized - Also available with a hinged door Usually partition walls are used to complete a stall, but sometimes a rear wall is needed: - Boards below – framed spindles above (optional screen in the feed area) - Boards below and above (optional spindle...

Cleaning System FRONT WALLS Cleaning System A sophisticated system has been developed to match the Standard and Professional stalls. PARTITION WALLS saves your strength Extendible partitions One-piece hinged front wall (sliding door) The front wall with sliding door can be opened. The complete wall opens almost 180 degrees into the aisle – the stall is then machine-accessible. 8 ... sim pl ifies e v e ryda y l ife es. in you r sta bl Two-piece hinged front wall (hinged door) This system is used for front walls with hinged doors. In addition to the hinged door, the fixed part of the front...

KRAFT Designer Horse Stalls HOHENLOHE SERIES KRAFT Designer Horse Stalls · HOHENLOHE SERIES rolling wave SANDBERG captivates with its wave KRAFT Designer Horse Stalls Hohenlohe – high-quality stable equipment and a feast for the eyes – here, for example, high quality EICHELGARTEN with round door posts Elegant stalls, timeless or modern – combined with elegant design. There are many combination options which can be individualized. In keeping with traditional stables of a bygone era, the KRAFT Designer Horse Stalls are furnished with noble ornamental posts, beautiful door fittings and...

KRAFT Designer Horse Stalls · HOHENLOHE SERIES KRAFT Designer Horse Stalls · HOHENLOHE SERIES classic Dutch doors Horse heads or round end caps on round door posts and vaulted arches create a classic and elegant appearance. RIEDWASEN is inspired by the historic stalls of days gone by. It can be combined well with brick masonry walls. The stall door can be equipped with a V-cutout upon request. Divided stall doors (Dutch doors) allow the top to be opened fully. RIEDWASEN integrated into a wooden girder construction The walls can be erected in a straight line or in the so-called V-line. Here,...

KRAFT Designer Horse Stalls · HOHENLOHE SERIES KRAFT Designer Horse Stalls · HOHENLOHE SERIES The designer horse stall EICHELGARTEN looks modern and simple. The front is divided into three parts in the low version. The straight door in the middle with slightly curved panels on the sides. straight lines SCHIMMELHOF is characterized by a simple and straightforward design. Characteristic are the heavy square door posts and a V-like cutout in the front wall with the low version. The partition walls can be also be designed with V-cutout. All door fittings are made of stainless steel. An arch is...

Exterior windows and doors Designed for a long life with horse-friendly aspects, KRAFT stable windows and doors are a valuable investment for your barn. KRAFT supplies carefully crafted windows, hatches, doors and gates for existing as well as new horse stables. Doors and windows shape the overall design of the exterior and must work flawlessly for many years. The construction requires expertise and knowledge to harmonize with the behavior of horses. We supply hinged or sliding components also custom made upon request. Professional window with wooden planks on the outside and bite guard on...

Windows and doors for stables Windows and doors for stables DOUBLE DOORS AND STALL DOORS SLIDING DOORS Sliding doors are convenient, easy to use and safe. There are single or double doors that come complete with top guide rail and bottom casters. All doors can be delivered rectangular or with an arch. Large double doors are available as vertically split double doors including a stall entrance door. Stall doors with tread and bite guards on the inside and V-grid insert in the upper part A beautiful stable front with hinged door as an integrated stable entrance door with diamond-shaped glass...

Exterior Stables Exterior Stables WITH SHED OR GABLE ROOF Rest and good care are very important for your horses. To accomplish this, you need protective accommodations with sufficient light and space. Our outdoor stables offer just that along with solid construction and variability in width and length. They are also Shed roof - Inexpensive and easy to install - External walls 2,300 mm high - Roof overhang approximately 1,250 mm - Well suited for expansion completely removable. Whether shed or gable roof, for smaller stables or larger units, with different roof coverings – we are flexible....
