CATALOGUE MALAGUTI CANGEO

CATALOGUE MALAGUTI CANGEO

Product catalog summary

Overview: The document outlines technical specifications and descriptions for various construction equipment attachments, emphasizing their compatibility with operating machines and intended applications. It advises comparing data with the machine's capacity.

1. Sheet Pile Clamps: Designed for vibro-driving and extracting sheet piles in diverse soil conditions, with optional features for pile extraction to protect anti-vibration mounts.

2. Hydraulic Kits: Lists different hydraulic kits for sheet pile clamps, detailing model numbers, hose configurations, and voltage options (V12, V24).

3. Bell and Rubber Kits: Designed for vibro-driving wooden, concrete, and steel piles, featuring a TOK adapter and interchangeable cushioning rubber to prevent damage to concrete piles.

4. T-Drilling Pre-Drill Bit: Used for creating pilot holes in hard ground, recommended for vibro-driving concrete piles, with a TOK adapter for direct attachment.

5. Compaction Plates: Details single and double bend compaction plates for compacting various surfaces, suitable for trenches, soils, and slopes.

6. T-Plates: Narrow plates ideal for compaction work in narrow trenches, particularly for laying fiber optic cables and underground utilities.

7. Storm Wheel Compactor: Ideal for compacting trench bottoms and backfill material, ensuring a solid and uniform base.

8. One Wheel Attachments: Designed for narrow trench compaction, suitable for laying cables and utilities, mountable directly onto machines without a vibration power unit.

9. Asphalt Cutter: Designed for cutting asphalt before trench excavation, mountable directly onto machines.

10. Front-Mounted Attachments: With PLURY front coupling, mountable on skid loaders and mini skid loaders, reducing vibrations transmitted to the carrier machine.

11. Double Compactor Plate: Offers effective, uniform compaction with a wide working surface, compatible with various loaders and suitable for different materials like gravel and soil.

Specifications: Lists technical specifications for different equipment models, including dimensions, weight, engine capacity, hydraulic fluid flow rate, vibration frequency, centrifugal force, and pressure limits.

Key Features:

High Vibration Frequency: Ensures deep and uniform compaction with fewer passes.
Robust and Reliable Design: Withstands heavy mechanical stress, reducing wear and maintenance costs.
Fast Maintenance: Components are easily accessible for simplified management.
High Productivity: Performs consistently on difficult terrain, ideal for public green areas, land clearing, and forestry work.

Equipment Types:

Vibratory Rollers: Used for compacting materials like asphalt and soil, featuring adjustable scarifiers and drum cleaning systems.
Mulchers: Available in knife and fixed-tooth versions, designed for cutting grass, brambles, and small shrubs, equipped with direct drive piston motors and anti-cavitation systems.
Stump Grinders: Designed for precise removal of stumps and roots, compatible with various loaders and excavators, featuring direct transmission systems for optimal productivity.

Recommendations: Data should be considered indicative and compared with the capacity of the operating machine. Proper selection and usage based on specifications ensure optimal performance and longevity.

General Sales Conditions:
Offers and Orders: Offers are non-binding; orders accepted upon written confirmation. Modifications or cancellations must occur within 24 hours.
Prices and Payment Terms: Based on current price list, excluding VAT and other costs. Late payments may incur interest and penalties.
Delivery Terms: Indicative and non-binding unless agreed in writing. Not liable for delays due to force majeure.
Warranty Terms: Products warranted for 12 months from dispatch; void if tampered with or used improperly.
Limitation of Liability: Not liable beyond warranty conditions, except for willful misconduct or gross negligence.
Intellectual Property: Trademarks and IP remain property of Malaguti s.r.l.
Personal Data Processing: Processed according to Italian law and GDPR.
Applicable Law and Jurisdiction: Governed by Italian law or CISG; disputes subject to Forlì Court jurisdiction.
General Provisions: Invalidity of any provision does not affect the rest; modifications must be in writing.

Catalog excerpts

From Giorgio Cangini’s experience, a new Premium line for Earthmoving

Open the catalog to page 1

ACCESSORI PLURY VIBRATION DRIVE 1.0 - 20.0 TONS VIBRATION DRIVE 6.0 - 40.0 TONS ACCESSORIES FOR VIBRATION DRIVES DOUBLE COMPACTOR PLATE FOR FRONT-MOUNTED MACHINES VIBRATORY ROLLERS FOR COMPACTION GRASS AND FORESTRY MULCHER STUMP GRINDER MULTIFUNCTION AUGER VIBRATORY SHEET PILE DRIVER

Open the catalog to page 3

THE ONLY MULTIFUNCTIONAL SOLUTION FOR COMPACTION AND DRIVING POSTS AND SHEET PILES. ADVANCED VERSION REV 2

Open the catalog to page 4

AVAILABLE FOR ALL OPERATING MACHINE TONNAGE RANGE VIBRATION POWER available with one or two eccentric shafts MULTIFUNCTION ACCESSORIES for compacting various types of ground and driving posts and sheet piles QUICK COUPLER for changing accessories quickly Flow control valve Stroke limiter Motor with HPS seal

Open the catalog to page 5

The flow control valve operates by limiting and stabilizing the incoming oil flow, so the attachment receives only the amount required to work under the correct operating conditions. This means that the same attachment can be installed on multiple excavators, loaders, or operating machines, without being strictly dependent on the specific hydraulic flow rate of each machine. OPTIONAL PILE EXTRACTION KIT Recommended to protect the anti-vibration mounts during the extraction of piles, sheet piles, etc. The data provided should be considered indicative and should be compared with the capacity of...

Open the catalog to page 6

■ vibrating mass ■directional force ■ vibrating mass ■ directional force Radial vibration, the centrifugal force producted is radially distributed over 360° Sinusoidal vibration, it vibrates vertically from top to bottom, concentrating the centrifugal force in the centre PLURY with bolted equipment PLURY with equipment attached via quick coupler The data provided should be considered indicative and should be compared with the capacity of the operating machine on which the equipment is used

Open the catalog to page 8

COMPACTION accessories for PLURY 9 The data provided should be considered indicative and should be compared with the capacity of the operating machine on which the equipment is used VIBRO-DRIVING accessories for PLURY

Open the catalog to page 9

OPTIONAL POST EXTRACTION KIT Recommended for use to protect the anti-vibration mounts. PLURY tONS 1124 *0

Open the catalog to page 10

OPTIONAL POST EXTRACTION KIT Recommended for use to protect the anti-vibration mounts. PLURY TOW260621 0 ✓ The FLOW CONTROL VALVE limits and stabilizes the incoming oil flow, so the equipment receives only the amount required to operate under the correct conditions.

Open the catalog to page 11

Model # A mm B mm C mm Kg. Model. PLURY TOK QUICK COUPLER B 530 100 240 29 W1 25 Model # A mm B mm C mm Kg. Model. PLURY TOK ADAPTER KIT B 230 170 200 13 W1 25 12 The data provided should be considered indicative and should be compared with the capacity of the operating machine on which the equipment is used

Open the catalog to page 12

ADAPTER FOR QUICK COUPLING A ADAPTER FOR QUICK COUPLING B ADAPTER FOR QUICK COUPLING C ADAPTER FOR QUICK COUPLING D + E + F + G ADAPTER FOR QUICK COUPLING H + I + L Model. PLURY Model # Model. PLURY FIXED COUPLING MACHINE A W1 14 FIXED COUPLING MACHINE B W1 25 FIXED COUPLING MACHINE C W1 45 FIXED COUPLING MACHINE D + E + F + G W1 60 | W1 90 | W2 62 | W2 92 FIXED COUPLING MACHINE H + I + L W2 125 | W2 185 | W2 220 BOLTED PLATE MACHINE COUPLING BOLTED PLATE MACHINE COUPLING BOLTED PLATE MACHINE COUPLING BOLTED PLATE MACHINE COUPLING BOLTED PLATE MACHINE COUPLING Model # Model. PLURY Model. PLURY...

Open the catalog to page 13

MECHANICAL SLEWING Model # A mm B mm C mm Kg. Model. PLURY Model # A mm B mm C mm Kg. Model. PLURY HYDRAULICS SLEWING Model # A mm B mm C mm Kg. Model. PLURY 5 Hoses €

Open the catalog to page 14

The mechanical slewing ring can be mounted on the excavator arm with an oscillating configuration. Mechanical rotation allows the attachment to rotate on itself up to 210° in partial rotation. It allows the machine to rotate on itself 360° with continuous rotation. The rotor is supplied complete with hoses. The rotor can be mounted on the PLURY only with mechanically operated accessories. It cannot be used with hydraulically operated accessories. The hydraulic slewing ring can be mounted using the excavator coupling, allowing the attachment to rotate 360° on itself. 15 The data provided should...

Open the catalog to page 15

Designed for vibrodriving and extracting wooden, concrete and steel posts. Suitable for landslide containment, embankments and riverbanks. Ideal for the construction of vineyards, orchards and fencing systems. VIBRATION POWER A fundamental combination, widely used in land maintenance and agriculture GRAPPLE with directly welded TOK ADAPTER MACHINE COUPLINGS the GRAPPLE can be mounted directly on the machine without drive. OPTIONAL POST EXTRACTION KIT Recommended for use to protect the anti-vibration mounts. The data provided should be considered indicative and should be compared with the capacity...

Open the catalog to page 16

HYDRAULIC KITS HYDRAULIC KITS 2 HOSES GRAPPLE 2 HOSES GRAPPLE 2 HOSES GRAPPLE 2 HOSES GRAPPLE # Model. PLURY CABLE COIL Volt Model. PLURY The data provided should be considered indicative and should be compared with the capacity of the operating machine on which the equipment is used

Open the catalog to page 17

KIT 1 KIT 2 Grapple accessory suitable for vibro-driving and extraction of concrete and steel poles. Pre-hole drill suitable for making a pre-hole in hard ground Suitable for vibro-driving concrete poles The data provided should be considered indicative and should be compared with the capacity of the operating machine on which the equipment is used

Open the catalog to page 18

KIT 3 KIT 4 Shock-absorbing rubber accessory suitable for vibrating concrete poles, avoiding damage to the pole itself Toothed plate mounted in place of the bell for vibratory driving of wooden piles of different diameters Replacement rubber pad for centering bell The data provided should be considered indicative and should be compared with the capacity of the operating machine on which the equipment is used

Open the catalog to page 19

H-BEAM CLAMP - H-BEAM VIBRO-DRIVING CLAMP Clamp designed for vibro-driving and extracting H-beams in various soil conditions. OPTIONAL FOR PILE EXTRACTION Recommended to protect the anti-vibration mounts. H-BEAM CLAMP with TOK adapter welded directly onto the clamp. H-BEAM CLAMP 20 GRIP D+E+F+G H+I+L Hydraulic Flow Model. PLURY 20 The data provided should be considered indicative and should be compared with the capacity of the operating machine on which the equipment is used
