Introduction
Muta, located in the valley of the river Drava, has a rich history of industrial activity dating back to the 16th century. Since 1973, Muta Agricultural Mechanisation Ltd. has been a leading manufacturer of small agricultural machinery in Slovenia, evolving from the GORENJE Group to meet global agricultural needs.

Product Development
The company initially developed the REX Combi mower, which led to the creation of the KOSOR single-axle tractors. The rapid global development prompted the introduction of the MAESTRAL, MINI, PROFI, and KOMBI machine families, designed for easy handling and quick attachment changes.

Technical Specifications

MAESTRAL: Features a 4-stroke petrol or diesel engine (5-7.3kw), 7 gears, drum brakes, and a weight of 92kg. It includes a height-adjustable handlebar and quick coupling for 60mm connectors.
MINI: Equipped with a 4-stroke engine (4-5.1kw), 4 gears, and a weight of 63kg. It has its own family of connectors, incompatible with MAESTRAL attachments.

Attachments for Grass Cutting

Finger Cutter Bar: Working width of 100-130cm, adjustable height from 3 to 7 cm, and a weight of 30 kg.
Rotary Mower: 80 cm working width, adjustable height from 3 to 7 cm, and a cutting capacity of 2000 m2/h.
Hammer Mulcher: Similar specifications to the Rotary Mower, with a weight of 52 kg.

Attachments for Land Treatment

Rotary Tillers: Working width of 60-70 cm, tilling depth of 14 cm, and a weight of 40 kg.
Rotary Plough: 18 cm working width, ploughing depth of 22 cm, and a weight of 36 kg.

Attachments for Cleaning and Snow

Rotary Snow Thrower: 60-80 cm working width, max snow height of 45 cm, and a 2-stage system.
Rotary Sweeper Snow Plough: 125 cm working width, 35-degree side tilt, and a weight of 49 kg.

Attachments for Transport

Trailer with Drive: Load capacity of 750 kg, loading surface size of 200x150x28 cm, and a weight of 350 kg.
Trailer KIP: Load capacity of 300 kg, loading surface size of 150x95x27 cm, and a weight of 90 kg.

Contact Information
MUTA, Agricultural Mechanisation Ltd., Koroška cesta 51, 2366 Muta, Slovenia. Email: [email protected], Tel: +386 (0)2 8770 111.

Catalog excerpts

TRADITON SINCE 1973 In the valley of the river Drava, surrounded by the beautiful forests of Pohorje and Kozjak, lies Muta. Here, in the second half of the 16th century, the Industrial Revolution began, transforming the town into one of the most important places in Carinthia. Despite the difficult times, industrial activity has survived to the present day. Muta, Agricultural Mechanisation's tradition of manufacturing small agricultural machinery dates back to 1973. In the 1970s, then still under the GORENJE Group, the company decided to develop new types of machines to meet the needs of farmers...

Open the catalog to page 2

TECHNICAL DETAILS ENGINE: 4-stroke petrol or diesel engine 5-7,3kw with recoil starter, max 3600 rpm ENGINE BRANDS: HONDA, YAMAHA, MAG, KOHLER TRANSMISSION 7 gears; 4 forward / 3 reverse RPM 786 rpm independent of gearbox BRAKES: Drum brakes on both wheels with the possibility of activating left and right brakes separately CONNECTION Quick coupling for 60mm diameter connectors HANDLEBAR: Height adjustable and 180-degree rotatable, also has an anti-vibration mechanism built-in WEIGHT: 92kg (depending on motor) WHEELS: 4.00x12 (other dimensions also possible) ATTENTION! OLDER MACHINES HAVE 80mm...

Open the catalog to page 3

TECHNICAL DETAILS ENGINE: 4-stroke petrol or diesel engine from 4 to 5.1kw TRANSMISSION: 4 gears; 2 forward / 2 reverse CONNECTION: Quick coupling for 60mm diameter connectors HANDLEBAR: Quick coupling for 60mm diameter connectors WEIGHT: 63kg ATTENTION! MINI has its own family of connectors and is not compatible with MAESTRAL family attachments.

Open the catalog to page 4

ATTACHMENTS FOR GRASS CUTTING TECHNICAL DETAILS WORKING WIDTH: 100, 130cm WORKING HEIGHT ADJUSTMENT: From 3 to 7 cm stepless RECOMMENDED WORK SPEED: From 2,5 to 4 km /h WEIGHT:30 kg (depending on blade width) TECHNICAL DETAILS WORKING WIDTH: 145cm WORKING HEIGHT ADJUSTMENT: From 3 to 7 cm stepless PRIPOROČENA DELOVNA HITROST: Od 2,5 do 4 km /h WEIGHT:30 kg (depending on blade width) TECHNICAL DETAILS WORKING WIDTH: 102, 132cm WORKING HEIGHT ADJUSTMENT: From 3 to 8 cm stepless PRIPOROČENA DELOVNA HITROST: From 2,5 to 4 km /h WEIGHT: 20 kg (depending on blade width) TECHNICAL DETAILS HOOD: 80mm...

Open the catalog to page 5

ATTACHMENTS FOR GRASS CUTTING ROTARY MOWER SCRUB MOWER HAMMER MULCHER TECHNICAL DETAILS WORKING WIDTH: 80 cm WORK HEIGHT ADJUSTMENT: 3 do 7 cm stepless CUTTING CAPACITY: 2000 m2/h WEIGHT: 52 kg TECHNICAL DETAILS WORKING WIDTH: 80 cm WORK HEIGHT ADJUSTMENT: 3 do 7 cm stepless CUTTING CAPACITY: 2000 m2/h WEIGHT: 52 kg TECHNICAL DETAILS WORKING WIDTH: 60 or 80 cm WORK HEIGHT ADJUSTMENT: 3 do 8 cm stepless CUTTING CAPACITY: 2000 m2/h WEIGHT: 40 kg (depending on width) WORKING WIDTH: 130 cm WORKING SYSTEM: Single-belt STEERING: Through the steering handlebar WEIGHT: 60 kg

Open the catalog to page 6

ATTACHMENTS FOR GRASS CUTTING MOWING SYSTEM WITH DUBLE CUTTER BAR TECHNICAL DETAILS WORKING WIDTH: 140 or 160 cm

Open the catalog to page 7

ROTARY TILLERS TECHNICAL DETAILS WORKING WIDTH: 60 or 70 cm TILLING DEPTH 14 cm WEIGHT: 40 kg TECHNICAL DETAILS WORKING WIDTH: 18 cm PLOUGHING DEPTH:22 cm WEIGHT: 36 kg SCHEDDING PLOUGH TECHNICAL DETAILS WORKING WIDTH: 30 or 60 cm DEPTH: 10 cm

Open the catalog to page 8

ATTACHMENTS FOR LAND TREATMENT CULTIVATOR TECHNICAL DETAILS WORKING WIDTH: 60 or 70 cm CULTIVATION DEPTH: 14 cm WEIGHT: 40 kg ATTACHMENTS FOR CLEANING AND SNOW ROTARY SNOW THROWER (2-STAGES) TECHNICAL DETAILS WORKING WIDTH: 60 or 80 cm MAX. SNOW HEIGHT: 45 cm SYSTEM: 2-stages SNOW PLOUGH TECHNICAL DETAILS WORKING WIDTH: 125 cm SIDE TILT: 35 degrees WEIGHT: 49 kg

Open the catalog to page 9

TRAILER WITH DRIVE TECHNICAL DETAILS LOAD CAPACITY: 750 kg SIZE OF LOADING SURFACE: 200x150x28 cm BRAKES: Drum brakes, with foot-operated parking lock WEIGHT: 350 kg TECHNICAL DETAILS LOAD CAPACITY: 300 kg SIZE OF LOADING SURFACE: 150x95x27 cm BRAKES: Drum brakes, with foot-operated parking lock WEIGHT: 90 kg

Open the catalog to page 10

TRANSPORT WHEELBARROW TECHNICAL DETAILS HALL: 120 L CART WITH SPECIAL SEAT WHEEL DISTANCE EXTENSION 60 or 105 mm ADDITIONAL WEIGHTS GRABBING WHEEL

Open the catalog to page 11

MUTA, Agricultural Mechanisation Ltd. Koroška cesta 51 2366 Muta Slovenija DDV ID: SI30144418 E-mail: [email protected] Tel. št. : +386 (0)2 8770 111 +386 (0)2 8770 110
