EVAPORATIVE COOLING MEDIA AND COOLING SYSTEMS

Evaporative panels PERIcool® are a simple and economical way to humidify the air in big spaces with minimum energetic costs thanks to the adiabatic process. A water distribution system pours the water into the evaporative panel in order to impregnate uniformly its special honeycomb structure. At this point the air passing through the panel partially transfers its heat to the water, causing its evaporation. The distributor panel guarantees a uniform pads wetting and higher performances Honeycomb structure specifically developed to achieve high performances A wide range of geometries is available...

Technical features TYPE 4545/7 Suitable for application conditions where a good balance between humidification efficiency and pressure drop is required. 100,0 Saturation efficiency (%) Saturation efficiency (%) TYPE 1545/7 Particularly suitable where low pressure drop as well as reasonable humidification efficiency are required. TYPE 3060/7 (version available on request - MOQ required) Suitable for application conditions where a good balance between humidification efficiency and pressure drop is required. Saturation efficiency (%) TYPE 4545/5 Suitable for application conditions where a good balance...

Optimal usage conditions Installation • Follow the product installation manual for correct installation • Keep the water tank away from direct sun light • Minimize the exposure of the evaporative panels to sunlight • Do not use hot water (water at room temperature only) • Do not wash with water under high pressure • Do not use products that contain chlorine, weed killers or any other chemical products • Use only clean water and a dry soft brush • Dry completely once every 24 hours • Minimize frequent wetting and drying cycles • During the operating season change the water weekly by removing the...

This product is made up by stainless steel gutter frames, without any addi-tional external water storage thanks to a special lower gutter, which serves as a tank. This innovative system is easy to install, permits to avoid all costs related to external tank with additional pipes. The lower gutter, although with the same design of the traditional one, has become deeper in order to contain the correct amount of water required by the system to operate. MDFX is appreciated not only by customers, but also by installers, maintenance workers and end-users for the simplicity and flexibility that distin-guish...

CLASSICGUTTER FRAME SYSTEM The frame system for evaporative cooling pads is made of pre-coated galvanised steel “Pluvimag”, and is suitable for installation in a harsh corrosive environment. Simplicity and flexibility are this product’s most distinguishing features and they are highly appreciated by our customers. MFP is designed for cooling appliance in the most various fields of application. The lower gutter is supported by reinforcements to guarantee rigidity and robustness The lower frame profile was specifically shaped to permit to drain the water completely The upper frame can be easily...

ID - water supply kit - the components of the water connection system to cool' evaporative cooling media, including the water flow control valve SC - water discharge kit -The components of the water discharge systems from the coo!' panels to the water tank F - filter -■ - - it contains water impurities GTP - hydraulic controller -Water level control valve BL - mineral discharge kit - by draining part of the water, the valve maintains a constant water hardness level and avoids damaging consequences such as calcification in the system ■ DOC - submersible pump - it allows the recirculation of the...

EVAPORATIVE COOLER The evaporative cooler PERIcooler is a very versatile machine, which can efficiently and economically cool down a big quantity of air. It is possible to use the product such in a fixed as well as in mobile configuration for temporary application. The sturdy frame of PERIcooler is made of steel with zinc/aluminum/magnesium coating for the maximum corrosion resistance. The cooling pads can be easily removed to ensure an easy maintenance and cleaning of the machine. The water tank has a great capacity (335 litres) in order to guarantee long continuous operation hours. Available...

Technical features Data related to PERIcooler at full operation. Dimensions and loading possibilities Technical features * Single-phase motors available upon request; all three-phase motors can be controlled by inverter. ** Measurement surface according to UNI EN ISO 3744. pic C.7. Loading possibilities *To optimize loading possibilities some parts can be supplied unassembled

WATER ATOMIZER RWA is a water atomizer with rotating disc to be installed on a circulating fan. It is produced in plastic in order to optimize weight and corrosion resistance. Each model can work with water at standard pressure without any nozzles in order to avoid any possible problem caused by calcification and water impurities. The water flow can be regulated according to the customer’s needs. Completely open RWA Turbo is a water atomizer with rotating disc and built-in propeller RWA Turbo O is a professional humidifier with integrated propeller and humidified air outlet diffuser

RWA SVG - fixing bar on square fans EOR-ERD-BKF SVX - fixing bar in stainless steel on square fans series EOR/ERD Aeternum Technical features, dimensions and loading possibilities Dimensions Note: measures are given in millimeters Technical features Note: 60 Hz version available upon request Loading possibilities All data in this catalogue are indicative and are subject to change without prior notice.

TEHMDTECNICnPEPICDLI TERMOTECNICA PERICOLI S.r.l. Regione Rapalline, 44 - 17031 Albenga, Italia tel. 0182 589006 fax 0182 589005 [email protected] PERICOLI ASIA PACIFIC Sdn. Bhd. PERICOLI CENTRO AMERICA PERICOLI MIDDLE EAST OBSESS' 68 P€R/coo/ are registered trademarks by Termotecnica Pericoli S.r.l.
