Bulk Seed Handling SEED RUNNER® Bulk Tender MODEL 3955XL & 3955DXL Serial Number D60240100 & Higher

Seed Runner 3955XL & 3955DXL — Introduction Foreword This symbol identifies important safety messages. When you see it, read the message that follows and be alert to the possibility of personal injury. Remember, safety instructions stated in this manual are for your protection. carefully and follow them closely when working around or using this machine. Read them Read and study this manual completely before attempting to operate this implement. Take this manual to the field for handy reference when operating, adjusting, or servicing your machine. When referenced, “Right-Hand” (RH) and “Left-Hand”...

Seed Runner 3955XL & 3955DXL — Introduction Product Information When ordering parts or when requesting further information or assistance, always give the following information: • • Machine name Serial number All products manufactured by Unverferth Mfg. Co., Inc. are warranted to be free from material and workmanship defects for one full year from time of consumer delivery. Your local dealer will gladly assist you with any warranty questions. Please fill out and retain this portion for your records. on the frame as shown below. The serial number plate is located Purchase Date___________________...

Seed Runner 3955XL & 3955DXL — Introduction

Seed Runner 3955XL & 3955DXL — Introduction

Seed Runner 3955XL & 3955DXL — Introduction

Seed Runner 3955XL & 3955DXL — Introduction

Seed Runner 3955XL & 3955DXL — Introduction

Seed Runner 3955XL & 3955DXL — Safety

Seed Runner 3955XL & 3955DXL — Safety General Hazard Information No accident-prevention program can be successful without the wholehearted cooperation of the person who is directly responsible for the operation of the equipment. A large number of accidents can be prevented only by the operator anticipating the result before the accident is caused and doing something about it. No power-driven equipment, whether it be transportation or processing, whether it be on the highway, in the field, or in the industrial plant, can be safer than the person who is at the controls. If accidents are to be prevented--and...

Seed Runner 3955XL & 3955DXL — Safety Safety Decals Replace lost, damaged, painted, or unreadable decals immediately. If parts that have decals are replaced, also make sure to install new decals. These decals inform and remind the operator with operational information and safety messages. Part Number 235161 Part Number 97961 Part Number 98350 Part Number 901580 Part Number 9501790 Part Number 98229 Part Number 901478 Part Number 97048 Part Number 9500345 Part Number 95445 Part Number TA1-906109-0

Seed Runner 3955XL & 3955DXL — Safety Following Safety Instructions • Read and understand this operator’s manual before operating. All machinery should be operated only by trained and authorized personnel. To prevent machine damage, use only attachments and service parts approved by the manufacturer. Always shut power unit and towing vehicle engine off and remove keys before servicing the seed tender. Avoid personal attire such as loose fitting clothing, shoestrings, drawstrings, pants cuffs, long hair, etc., that may become entangled in moving parts. Do not allow anyone to ride on the implement....

Seed Runner 3955XL & 3955DXL — Safety • Regulate speed to field conditions. Maintain complete control at all times. • Never service or lubricate equipment when in operation. • Keep away from overhead power lines. Electrical shock can cause serious injury or death. • Use extreme care when operating close to ditches, fences, or on hillsides. • Do not leave towing vehicle or Seed Tender unattended with engine running. • Carbon monoxide can cause severe nausea, fainting or death. Do not operate engine in closed or confined area. • Explosive fuel can cause fires and severe burns. Stop engine before...

Seed Runner 3955XL & 3955DXL — Safety Before Transporting • Secure transport chains to towing vehicle before transporting. DO NOT transport without chains. Install transport locks before transporting. Check for proper function of all available transport lights. Make sure that all reflectors are clean and in place on machine. Make sure that the SMV emblem and SIS decal are visible to approaching traffic. During Transport Comply with all laws governing highway safety when moving machinery. Use transport lights as required by all laws to adequately warn operators of other vehicles. Regulate speed...

Seed Runner 3955XL & 3955DXL — Safety Pressurized Oil • Relieve the hydraulic system of all pressure before adjusting or servicing. See hydraulic power unit manual for procedure to relieve pressure. High-pressure fluids can penetrate the skin and cause serious injury or death. Leaks of high-pressure fluids may not be visible. Use cardboard or wood to detect leaks in the hydraulic system. Seek medical treatment immediately if injured by high-pressure fluids. Hydraulic system must be purged of air before operating to prevent serious injury or death. Do not bend or strike high-pressure lines. Do...

Seed Runner 3955XL & 3955DXL — Safety Preparing for Emergencies • Keep a first aid kit and properly rated fire extinguisher nearby. Keep emergency numbers for fire, rescue, and poison control personnel near the phone. Wearing Protective Equipment Wear clothing and personal protective equipment appropriate for the job. Wear steel-toed shoes when operating. Wear hearing protection when exposed to loud noises. Do not wear additional hearing impairing devices such as radio headp

After the Seed Runner tender has been completely assembled, use the following checklist and inspect the following items. Check off each item as it is found satisfactory or after proper adjustment is made. □ Torque wheel nuts as specified in Maintenance section. □ Torque all axle mounting hardware to 120 ft.-lbs. □ Check to make sure the lift assist tension bolt for the 8” conveyor has 1 5/8” measurement. □ Tires are inflated to specified air pressure. □ All grease fittings have been lubricated. □ Check to be sure all safety decals are correctly located and legible. Replace if damaged. □ Check...
