A DIVISION OF VAN RIJN ENTERPRISES LTD. R.R. #1,7367 YOUNG STREET, GRASSIE, ONTARIO, CANADA L0R 1M0 PHONE 905-945-8863 FAX 905-945-9294 We realize, that with continuing cost increases, each dollar must be well spent. Because we feel much the same, together, we can help you achieve: - SIGNIFICANT SAVINGS IN HEATING COSTS - SIGNIFICANT SAVINGS IN COOLING COSTS - REDUCED WATERING AND FERTILIZER COSTS - REDUCED CONDENSATE DRIP - A MORE BALANCED GROWING ENVIRONMENT - BETTER QUALITY AND MORE CONSISTENT CROPS - A REDUCTION IN TIME AND LABOUR REQUIRED - A MORE COMFORTABLE WORKING ENVIRONMENT We have...

A DIVISION OF VAN RIJN ENTERPRISES LTD. R.R. #1, 7367 YOUNG STREET, GRASSIE, ONTARIO, CANADA L0R 1M0 PHONE 905-945-8863 FAX 905-945-9294 A Few Words About the VRE Shade & Save™ System The shading, black out and/or heat retention system consists of an electric motor driven gear box, complete with reversing controls and built in travel limit switches to control the open (uncovered) and closed (covered) positions. It includes an emergency cut out limit switch in case of malfunction by the travel limit switches. Each drive unit mounted beneath the system is connected to a pipe drive shaft by means...

A DIVISION OF VAN RIJN ENTERPRISES LTD. R.R. #1, 7367 YOUNG STREET, GRASSIE, ONTARIO, CANADA L0R 1M0 PHONE 905-945-8863 FAX 905-945-9294 Aluminum Extrusion The VRE EXTRUSION incorporates a flexible rubber sealing strip, which forms a positive closure when the system is closed. The VRE EXTRUSION forms the support for the system configuration, which then ensures a neat and small fabric bundle when the system is in the open (uncovered) position. By means of a special fabric clip, the fabric of the adjoining cover is fastened to the back of the VRE EXTRUSION, which means simpler installation, reduces...

A DIVISION OF VAN RIJN ENTERPRISES LTD. R.R. #1, 7367 YOUNG STREET, GRASSIE, ONTARIO, CANADA L0R 1M0 PHONE 905-945-8863 FAX 905-945-9294 SHADE & SAVE™ Truss-to-Truss Peak System A Truss-to-Truss Peak system has many advantages: - All of the covers in a given greenhouse or range of greenhouses can be tied together in order to move simultaneously and can be operated from the same drive unit. - Because the Truss-to-Truss Peak system is installed above overhead obstructions, there is more usable space for hanging baskets, etc., and allows for the installation of extra lighting and the use of circulating...

A DIVISION OF VAN RIJN ENTERPRISES LTD. R.R. #1, 7367 YOUNG STREET, GRASSIE, ONTARIO, CANADA L0R 1M0 PHONE 905-945-8863 FAX 905-945-9294 SHADE & SAVE™ Truss-to-Truss Flat System Covers installed in a Truss-to-Truss Flat configuration are most economical in terms of hardware and amount of cover fabric used as well as being most efficient in heat retention capability. Suitable for single house installations, this configuration is also easily adapted to multiple house ranges or the future connection of additional houses. This installation is not recommended where there are obstructions such as posts,...

A DIVISION OF VAN RIJN ENTERPRISES LTD. R.R. #1, 7367 YOUNG STREET, GRASSIE, ONTARIO, CANADA L0R 1M0 PHONE 905-945-8863 FAX 905-945-9294 SHADE & SAVE™ Gutter-to-Gutter Flat System As with the Truss-to-Truss Flat configuration, covers installed in a Gutter-to-Gutter Flat configuration are also economical in terms of hardware and amount of cover fabric used as well as being efficient in heat retention capability. This configuration is more suited to multiple house ranges or the future extension of the greenhouse length. This system type also requires 10"-12" clearance between bottom of gutter or...

A DIVISION OF VAN RIJN ENTERPRISES LTD. R.R. #1, 7367 YOUNG STREET, GRASSIE, ONTARIO, CANADA L0R 1M0 PHONE 905-945-8863 FAX 905-945-9294 We would like to hear from you. Please return the following completed form so we can discuss your requirements. COMPANY NAME ATTENTION ADDRESS PROV./ POSTAL CODE/ CITY STATE ZIP CODE PHONE NO. FAX NO. BEST TIME TO CALL E-MAIL GENERAL INFORMATION PURPOSE OF SYSTEM: Heat Retention Photo Period Partial Shade Roll Up Walls Other CROP GROWN MAKE OF GREENHOUSE

A DIVISION OF VAN RIJN ENTERPRISES LTD. R.R. #1,7367 YOUNG STREET, GRASSIE, ONTARIO, CANADA L0R 1M0 PHONE 905-945-8863 FAX 905-945-9294 VRE Systems COST ESTIMATE REQUISITION TITLE STATEZIP CODE FAX #:BEST TIME TO CALL _DATE REQ'D:_ PURPOSE OF SYSTEM □ HEAT RETENTION □ PHOTOPERIOD □ PARTIAL SHADE □_ CITY PHONE #: EMAIL:_ GENERAL INFORMATION GREENHOUSE APPLICATION □ FLORICULTURE □ FOLIAGE □ VEGETABLES □ RETAIL □ SYSTEM CONFIGURATION □ PEAK, TRUSS TO TRUSS □ FLAT, TRUSS TO TRUSS | | FLAT, GUTTER TO GUTTER TYPE OF FABRIC (All fabrics provide some heat retention). THE NUMBERS IN EACH PRODUCT CODE...

Systems A DIVISION OF VAN RIJN ENTERPRISES LTD. R.R. #1,7367 YOUNG STREET, GRASSIE, ONTARIO, CANADA L0R 1M0 PHONE 905-945-8863 FAX 905-945-9294 NUMBER OF HOUSES NUMBER OF ZONES _ GREENHOUSE DIMENSIONS HOUSE WIDTH B- HOUSE LENGTH C RAFTER LENGTH D or J_ WALL HEIGHT A LOWER WALL HEIGHT E_ UPPER WALL HEIGHT F_ POST SPACING CENTRE_ SIDE WALLS GABLE ENDS VENTILATION □ PEAK ROOF VENTS □ GUTTER ROOF VENTS □ SIDE VENT AND FANS □ GABLE VENT AND FANS □ SHUTTERS AND FANS □ SIZE OF ABOVE TYPE OF GLAZING □ GLASS □ DYNAGLASS □ DOUBLE POLY □ TWINWALL □ TYPE OF GUTTER POST □ O SIZE- PLEASE INCLUDE A ROUGH SKETCH...
