Dynamic Disc Plus

Product catalog summary

Overview: The Dynamic Disc Plus is a high-performance, tractor-mounted precision spaced planter designed for maximum precision in seed placement. It is suitable for multi-crop applications, including corn, cereals, and rapeseed, with row spacings starting at 20 cm (7.8 inches). The planter ensures 100% seed purity and can operate at speeds up to 5 km/h (3.2 mph).

Key Features:

Slotted disk principle for gentle seed separation.
Row-independent electric sowing drive for flexible plot design.
Modern Easy Plant planting software for enhanced operation.
Optional Smart Feed automatic seed feeding system.

Technical Specifications:

Seed Types: Maize, soybeans, sunflowers, wheat, barley, rape, beets, beans, peas.
Mounting Options: 3-point hydraulic system on tractor or towed version.
Track Width: Varies based on the basic machine selected.
Number of Rows: Up to 12, with other configurations available on request.
Row Spacing: 20 cm to 96 cm (8 to 38 inches), hydraulically adjustable.
Seed Spacing: Continuously adjustable per row using the electric drive.
Supply Unit Drive: Via PTO shaft or tractor hydraulics.

Feeding Options:

Single funnel per row.
Central seed distributor for 2, 4, or 6 rows.
Magazine unit for 4- or 6-row automatic feeding.

Available Openers:

Double disk opener for 45 cm (18 inches) and 20 cm (8 inches) row spacing.
Suffolk coulter version for 20 cm (8 inches) row spacing.

Additional Options: Micro granulate, fertilizer, wind and rain cover, working lights, barcode scanner.

Dimensions:

Length: From approx. 1900 mm (75 inches).
Width: From 2500 mm (99 inches).
Height: Approx. 2200 mm (87 inches).
Weight: From 1700 kg (3,740 lbs).

Note: Technical alterations may be made without notice.

Catalog excerpts

Dynamic Disc Plus The Dynamic Disc has been specially designed to meet very high performance requirements for precision spaced planting of trial plots. Very high planting capacity can be achieved thanks to a patented sowing system, able to be mounted on basic frames by various manufacturers. Thanks to precise seed singulation, the Dynamic Disc Plus high-performance, tractor-mounted precision spaced planter prevents skipped seeds and doubles during seed placement. The Dynamic Disc Plus can be optionally equipped with the Smart Feed automatic seed feeding system. Your benefits summed up: • Maximum precision during seed placement • Especially gentle separation thanks to slotted disk principle • Very suitable for multi-crop applications with various crop types ranging from corn to cereals to rapeseed starting at row spa-cings of 20 cm (7.8") • 100 % seed purity in the seed metering unit • Maximum planting speed of up to 5 km/h (3.2mph) • Maximum flexibility for designing plots and placing seed thanks to row-independent electric sowing drive • Modern Easy Plant planting software

Open the catalog to page 1

Dynamic Disc Plus We reserve the right to make technical alterations.
